Splunk SPLK-1003 Exam Questions

The correct answer is B. in props.conf:

[identity]

SEDCMD-redact_pw = s/password=([^,|/s]+)/ ####REACTED####/g

According to the Splunk documentation1, to redact sensitive data from raw events, you need to use the SEDCMD attribute in the props.conf file. The SEDCMD attribute applies a sed expression to the raw data before indexing. The sed expression can use the s command to replace a pattern with a substitution string. For example, the following sed expression replaces any occurrence of password= followed by any characters until a comma, whitespace, or slash with ####REACTED####:

s/password=([^,|/s]+)/ ####REACTED####/g

The g flag at the end means that the replacement is applied globally, not just to the first match.

Option A is incorrect because it uses the REGEX attribute instead of the SEDCMD attribute. The REGEX attribute is used to extract fields from events, not to modify them.

Option C is incorrect because it uses the transforms.conf file instead of the props.conf file. The transforms.conf file is used to define transformations that can be applied to fields or events, such as lookups, evaluations, or replacements. However, these transformations are applied after indexing, not before.

Option D is incorrect because it uses both the wrong attribute and the wrong file. There is no REGEX-redact_pw attribute in the transforms.conf file.

References: 1: Redact data from events - Splunk Documentation

The correct answer is B. The network input in Splunk might be found in the $SPLUNK_HOME/etc/apps/$appName/local/inputs.conf file.

A network input is a type of input that monitors data from TCP or UDP ports. To configure a network input, you need to specify the port number, the connection host, the source, and the sourcetype in the inputs.conf file. You can also set other optional settings, such as index, queue, and host_regex1.

The inputs.conf file is a configuration file that contains the settings for different types of inputs, such as files, directories, scripts, network ports, and Windows event logs. The inputs.conf file can be located in various directories, depending on the scope and priority of the settings. The most common locations are:

$SPLUNK_HOME/etc/system/default: This directory contains the default settings for all inputs. You should not modify or copy the files in this directory2.

$SPLUNK_HOME/etc/system/local: This directory contains the custom settings for all inputs that apply to the entire Splunk instance. The settings in this directory override the default settings2.

$SPLUNK_HOME/etc/apps/$appName/default: This directory contains the default settings for all inputs that are specific to an app. You should not modify or copy the files in this directory2.

$SPLUNK_HOME/etc/apps/$appName/local: This directory contains the custom settings for all inputs that are specific to an app. The settings in this directory override the default and system settings2.

Therefore, the best practice is to create or edit the inputs.conf file in the $SPLUNK_HOME/etc/apps/$appName/local directory, where $appName is the name of the app that you want to configure the network input for. This way, you can avoid modifying the default files and ensure that your settings are applied to the specific app.

The other options are incorrect because:

A . There is no network directory under the apps directory. The network input settings should be in the inputs.conf file, not in a separate directory.

C . There is no udp.conf file in Splunk. The network input settings should be in the inputs.conf file, not in a separate file. The system directory is not the recommended location for custom settings, as it affects the entire Splunk instance.

D . The var/lib/splunk directory is where Splunk stores the indexed data, not the input settings. The homePath setting is used to specify the location of the index data, not the input data. The inputName is not a valid variable for inputs.conf.

The correct answer is C. Distributed search is the feature that allows search heads in a company's European offices to search data in their New York offices. Distributed search also enables restricting access to certain indexers by using the splunk_server field or the server.conf file1.

Distributed search is a way to scale your Splunk deployment by separating the search management and presentation layer from the indexing and search retrieval layer. With distributed search, a Splunk instance called a search head sends search requests to a group of indexers, or search peers, which perform the actual searches on their indexes. The search head then merges the results back to the user2.

Distributed search has several use cases, such as horizontal scaling, access control, and managing geo-dispersed data. For example, users in different offices can search data across the enterprise or only in their local area, depending on their needs and permissions2.

The other options are incorrect because:

A . Indexer clustering is a feature that replicates data across a group of indexers to ensure data availability and recovery. Indexer clustering does not directly affect distributed search, although search heads can be configured to search across an indexer cluster3.

B . LDAP control is a feature that allows Splunk to integrate with an external LDAP directory service for user authentication and role mapping. LDAP control does not affect distributed search, although it can be used to manage user access to data and searches.

D . Search head clustering is a feature that distributes the search workload across a group of search heads that share resources, configurations, and jobs. Search head clustering does not affect distributed search, although the search heads in a cluster can search across the same set of indexers.

The HTTP Event Collector (HEC) supports indexer acknowledgment to confirm event delivery. Each acknowledgment is associated with a unique GUID (Globally Unique Identifier).

GUID ensures events are not re-indexed in the case of retries.

Incorrect Options:

B, C, D: These are not valid channel values in HEC acknowledgments.

References:

Splunk Docs: Use indexer acknowledgment with HTTP Event Collector

The correct answer is C. On Deployment Server, $SPLUNK_HOME/etc/deployment-apps.

A deployment server is a Splunk Enterprise instance that acts as a centralized configuration manager for any number of other instances, called ''deployment clients''. A deployment client can be a universal forwarder, a non-clustered indexer, or a search head1.

A deployment app is a directory that contains any content that you want to download to a set of deployment clients. The content can include a Splunk Enterprise app, a set of Splunk Enterprise configurations, or other content, such as scripts, images, and supporting files2.

You create a deployment app by creating a directory for it on the deployment server. The default location is $SPLUNK_HOME/etc/deployment-apps, but this is configurable through the repositoryLocation attribute in serverclass.conf. Underneath this location, each app must have its own subdirectory. The name of the subdirectory serves as the app name in the forwarder management interface2.

The other options are incorrect because:

A) On Universal Forwarder, $SPLUNK_HOME/etc/apps. This is the location where the deployment app resides after it is downloaded from the deployment server to the universal forwarder. It is not the location of the app before it is deployed2.

B) On Deployment Server, $SPLUNK_HOME/etc/apps. This is the location where the apps that are specific to the deployment server itself reside. It is not the location where the deployment apps for the clients are stored2.

D) On Universal Forwarder, $SPLUNK_HOME/etc/deployment-apps. This is not a valid location for any app on a universal forwarder. The universal forwarder does not act as a deployment server and does not store deployment apps3.
